LS-A6 6 cavity fully automatic plastic water bottle making machine for 100ML to 2L PET bottles

LS-A6 6 cavity fully automatic plastic water bottle making machine for 100ML to 2L PET bottles

LS-A6 full automatic plastic bottle stretch blow moulding machines can produce different shapes from 100ML to 2L carbonated bottles, mineral bottles, pesticide bottles, cosmetic bottle and other plastic PET containers. High speed,low defect rate,stable running and easy operation.

Machine Parts

  • a.PLC controller touch screen : SIEMENS(Germany)
  • b.Pneumatic parts:AIRTAC(TAIWAN)/SMC(Japan)
  • c.Controller of stretch ,shift ,clamping servo motor : SIEMENS(Germany)
  • d.Other parts are world-famous brands

Follow us on

Machine Features

  • A.Advanced PLC control system and touch screen with convenient operation.
  • B.High efficiency automatic preform loading device.
  • C.Precise infrared heating, the preform rotates by itself and on the orbit at the same time, with strong penetration and high heating efficiency.
  • D.High security ,when a failure occurs during action or machine running,the program will alarm immediately and display the cause of the failure.
  • E.Two ways of operate: automatic and manual.
  • F.Customized machine design saves space and energy.
  • G.Simple installation and operation.

Product Detail

Model NO.

  LS-A8

  LS-A6

   LS-A4

  LS-A2

LS-A3

Theoretical Output

11000pcs/hr

6500pcs/hr

5000pcs/hr

2500pcs/hr

3000pcs/hr

Max.Container Volume

1L

2.0L

2.0L

2.0L

750ML

Max. Neck Diameter

45mm

45mm

45mm

45mm

45mm

Max. Container Diameter

80mm

100mm

100mm

100mm

100mm

Max. Container Height

270mm

340mm

340mm

340mm

340mm

Number Of Cavity

8 cavity

6 cavity

4 cavity

2 cavity

3cavity

Total Power

65kw

45kw

35kw

25kw

25kw

Use Power

40kw

30kw

20kw

12kw

12kw

Working Pressure

1.0mpa

1.0mpa

1.0mpa

1.0mpa

1.0mpa

Low Pressure Consuming

1600L/min

1600L/min

1600L/min

1400L/min

1200L/min

Blow Pressure

3.5mpa

3.5mpa

3.0mpa

3.0mpa

3.0mpa

High Pressure Consuming

4200L/min

3600L/min

2400L/min

1200L/min

1200L/min

Machine Size

6.8x2.0x2.0m

4.8x1.5x2.0m

4.2x1.4x2.0m

1.9x1.6x2.0m

1.9*1.6*2.0m

Machine Weight

    6.5T

    5T

     2.2T

    1.3T

1.3T

Feeding Machine Size

2.0x1.2x2.2m

2.0x1.2x2.2m

2.0x1.0x2.0m

2.0x1.0x2.0m

2.0x1.0x2.0m

Feeding Machine Weight

    0.3T

    0.3T

    0.22T

    0.2T

0.2T

 *Acceptable: Customize the machine according to the bottle size. Customize accessories and colors.
