LS-B5L 2 cavity manual 100ML To 7L Bottles 5L PET bottle machine maker

LS-B5L 2 cavity manual 100ML To 7L Bottles 5L PET bottle machine maker

LS-B5L semi automatic 5L bottle blowing machine can produce different shapes from 100ML to 7L carbonated bottle, mineral water bottle, pesticide bottle, juice bottle,cosmetics bottles, and other plastic PET containers. High quality,low defect rate,easy operation.

Machine Parts

  • a.PLC controller and screen : Thinget(China)
  • b.Pneumatic parts:YongCheng (China)/Festo(Germany)
  • c.Valve parts: STNC (China)
  • d.Other parts are world-famous brands

Follow us on

Machine Features

  • A.Advanced PLC control system with convenient operation.
  • B.Precise infrared heating, the preform rotates by itself and on the orbit at the same time, with strong penetration and high heating efficiency.
  • C.Two ways of operate: automatic and manual.
  • D.Safety, high efficiency and energy saving.
  • E.Simple installation and operation.
  • F.Long time after sales service.

Product Detail

Model

LS-B5L

Theoretical output

800BPH

Heating capacity

18KW

Max bottle  volume

7L -2cavity

Blowing pressure

≦3.0MPA

Motion pressure

≦1.0MPA

Max diameter*height

Φ260*H430

Mould thickness

260-430MM

Weight

1300KGS

Main machine size

1800*620*1700MM

Heater size

1700*650*1450MM
